Element Symbol

Properties and Overview of Boron

Overview:

Image of Boron or Application Boron (B) is a chemical element with the symbol B and atomic number 5 on the periodic table. It is a metalloid, meaning it has properties of both metals and non-metals. Boron is found in nature primarily in compounds rather than in its pure elemental form. It is essential in various industrial applications and has significant roles in agriculture, electronics, and materials science. Boron exists in several allotropes, with amorphous boron as a brown powder and crystalline boron as a black, extremely hard material. It has a high melting point of about 2,075°C and a boiling point of 3,927°C. Boron is known for its hardness and low density, making it valuable in applications requiring light and strong materials. It is a poor conductor of electricity at room temperature but a good conductor at higher temperatures.
Boron is chemically versatile, displaying behavior characteristic of both metals and non-metals. Boron compounds, such as boric acid (H3BO3), borates, and boron carbide (B4C), are significant in various industrial and chemical processes. Boron is also known for forming stable covalent networks, such as in boron nitride, which has a structure similar to carbon-based materials like graphite and diamond.
Boron and its compounds are generally considered to have low toxicity. Elemental boron is not hazardous, but some boron compounds, such as boric acid, can be toxic in large amounts. Boron compounds are used in many household products, including laundry detergents and insecticides, where they are considered safe when used correctly. However, inhalation of boron-containing dust or prolonged skin exposure to certain boron compounds can irritate, so appropriate safety measures, such as protective clothing and ventilation, should be used in industrial settings.


Production:

Boron is not found freely in nature; it is typically extracted from minerals such as borax (sodium borate) and kernite. The primary sources of boron are found in arid regions, notably in Turkey, the United States, and South America. The production process involves mining boron-containing minerals refined to produce boric acid, borax, or elemental boron. The extraction of pure boron is a complex process, often involving the reduction of boron compounds with metals like magnesium or aluminium at high temperatures.


Applications:

Due to its unique properties, boron has a wide range of applications. One of the most significant uses is producing strong and lightweight materials. Boron fibers and boron-containing ceramics are used in aerospace, military, and sports equipment for their strength and durability. Boron is also critical in the glass and ceramics industry, where borates improve thermal and chemical resistance.
Boron is an essential micronutrient for plants in agriculture. It plays a key role in cell wall formation and reproductive development. Boron-containing fertilizers are used to correct boron deficiencies in crops.
In electronics, boron is used as a doping agent in semiconductors to modify the electrical properties of silicon, which is crucial for manufacturing transistors and other electronic components. Due to its high neutron cross-section, boron is also used to produce strong magnets and as a neutron absorber in nuclear reactors, which helps control the nuclear fission process.


Summary:

Boron is a versatile and essential element with applications across various industries. From strengthening materials and enhancing glass properties to its critical role in electronics and agriculture, boron's unique physical and chemical properties make it invaluable in industrial and scientific contexts. While generally safe, appropriate precautions should be taken when handling boron compounds, particularly in industrial environments, to minimize potential health risks. Boron's role will likely expand as technology and industry evolve, underscoring its significance in modern science and engineering.



See a comprehensive list of atomic, electrical, mechanical, physical and thermal properties for boron below:



Atomic Structure of Boron

Image of Boron Structure

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Atomic Properties of Boron

Atomic Property (Units) Value
Boron Atomic Electron Configuration [He] 2s22p1
Boron Atomic Mass (amu) 10.81
Boron Atomic Number 5
Boron Chemical Element Symbol B
Boron Covalent Radius (Å) 0.84
Boron Crystal Structure Rhombohedral
Boron Electronegativity (Pauling Scale) 2.04
Boron Electrons per Orbital Shell (inner most first) 2, 3
Boron Half-Life (Years) N/A - Stable
Boron Lattice Parameter / Lattice Constant (Å) a = 5.06, c = 5.06
Boron Number of Electron Orbital Shells 2
Boron Number of Electrons 5
Boron Number of Neutrons 5
Boron Number of Protons 5
Boron Periodic Table Series Metalloids
Boron Phase at 'Standard Temperature and Pressure' Solid
Boron Stable Isotopes B-10, B-11

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Electrical Properties of Boron

Electrical Property (Units) Value
Boron Dielectric Constant at 'Standard Temperature and Pressure' Unknown
Boron Electrical Breakdown Voltage at Atmospheric Pressure (kV/mm) Unknown
Boron Electrical Conductivity (S/m) 1E-06
Boron Electrical Resistivity at Room Temperature (25°C) (Ω·m) 1E+06
Boron Magnetic Property Diamagnetic
Boron Superconducting Transition Temperature (K) N/A - Not a Super Conductor
Boron Temperature Coefficient of Resistance (°C⁻¹) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Mechanical Properties of Boron

Mechanical Property (Units) Value
Boron Compressive Strength (MPa) Unknown
Boron Ductile to Brittle Transition Temperature (°C) Unknown
Boron Fatigue Limit (MPa) Unknown
Boron Fracture Toughness (MPa·√m) Unknown
Boron Hardness Brinell Unknown
Boron Hardness Rockwell Unknown
Boron Hardness Vickers Unknown
Boron Heat Deflection Temperature (°C) N/A - Not a Polymer
Boron Modulus of Elasticity / Young's Modulus (GPa) Unknown
Boron Percent Elongation (%) Unknown
Boron Poissons Ratio Unknown
Boron Shear Modulus (GPa) Unknown
Boron Shear Strength (MPa) Unknown
Boron Ultimate Tensile Strength (MPa) Unknown
Boron Yield Strength (MPa) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Physical Properties of Boron

Physical Property (Units) Value
Boron Boiling Point at Atmospheric Pressure (°C) 3927
Boron Chemical Composition (Element %) B
Boron Cost ($/kg) 45570
Boron Density at 'Standard Temperature and Pressure' (kg/m3) 2460
Boron Glass Transition Temperature at Atmospheric Pressure (°C) N/A
Boron Melting Point at Atmospheric Pressure (°C) 2075
Boron Polymer Family N/A - Not a Polymer
Boron Refractive Index 2.419 (Boron Nitride)
Boron Specific Gravity 2.46
Boron Viscosity at Melting Point (mPa·s) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Thermal Properties of Boron

Thermal Property (Units) Value
Boron Coefficient of Thermal Expansion (µm/m·K) 5
Boron Emissivity Coefficient 0.7 - 0.8
Boron Specific Heat Capacity (J/kg·K) 1026
Boron Thermal Conductivity (W/m.K) 27.4
Boron Thermal Conductivity (BTU/h·ft·°F) 15.84
