Properties and Overview of Chlorine

Overview:

Image of Chlorine or Application Chlorine (Cl) is a chemical element with the symbol Cl and atomic number 17 on the periodic table. It is a member of the halogen group, which also includes fluorine, bromine, iodine, and astatine. As a halogen, Chlorine is a highly reactive element that plays a significant role in various chemical reactions and processes. Physically, Chlorine is a yellow-green gas under standard conditions. It has a sharp, pungent odor that is easily recognizable even at low concentrations. Chlorine gas is denser than air, which can accumulate in low-lying areas. When cooled, Chlorine condenses into a pale yellow-green liquid, and when further cooled, it solidifies into a crystalline structure. The melting point of Chlorine is approximately -101°C and its boiling point is -34°C.
Chemically, Chlorine is highly reactive, particularly with hydrogen, and forms a wide range of compounds. One of the most well-known reactions involving Chlorine is with sodium to form sodium chloride, commonly known as table salt. Chlorine is a powerful oxidizing agent that can gain electrons during chemical reactions. This property makes it effective in breaking down organic materials, which is why it is widely used for disinfection and bleaching. Chlorine reacts with water to form hydrochloric acid (HCl) and hypochlorous acid (HClO), a reaction utilized in water treatment processes to kill bacteria and other pathogens.
Safety is critical when handling Chlorine due to its highly reactive nature and toxic effects. Chlorine gas is highly irritating and can be harmful if inhaled, causing damage to the respiratory system. In high concentrations, chlorine exposure can lead to coughing, choking, and severe respiratory distress, potentially resulting in death. Direct contact with Chlorine in its gaseous or liquid form can also cause burns to the skin and eyes. Because of these hazards, stringent safety measures are required when storing and handling Chlorine, including protective equipment such as gas masks, gloves, and chemical-resistant clothing. In industrial settings, Chlorine is often stored in pressurized containers, and leak detection systems are used to monitor accidental releases.


Production:

Chlorine is primarily produced by the electrolysis of sodium chloride (salt) dissolved in water, known as the chlor-alkali process. This process also yields sodium hydroxide and hydrogen gas as byproducts. There are several methods for the electrolysis of sodium chloride, including the diaphragm cell process, the membrane cell process, and the mercury cell process. The membrane cell process is today's most commonly used method due to its lower environmental impact and higher energy efficiency.


Applications:

In terms of applications, Chlorine has a wide range of uses across various industries. One of its most important roles is in water purification and sanitation. Chlorine is used to disinfect drinking water and swimming pools, helping to prevent the spread of waterborne diseases. It is also used to produce various consumer goods, such as bleach, plastics (like polyvinyl chloride or PVC), solvents, and pesticides. In the chemical industry, Chlorine is a critical intermediate in producing many organic and inorganic compounds, including pharmaceuticals, dyes, and refrigerants.


Summary:

Chlorine is a versatile and essential chemical with many applications. However, its reactive nature and potential health hazards necessitate careful handling and strict safety protocols to minimize risks associated with its use.



See a comprehensive list of atomic, electrical, mechanical, physical and thermal properties for chlorine below:



Atomic Structure of Chlorine

Image of Chlorine Structure

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Atomic Properties of Chlorine

Atomic Property (Units) Value
Chlorine Atomic Electron Configuration [Ne] 3s23p5
Chlorine Atomic Mass (amu) 35.45
Chlorine Atomic Number 17
Chlorine Chemical Element Symbol Cl
Chlorine Covalent Radius (Å) 1.02
Chlorine Crystal Structure Orthorhombic
Chlorine Electronegativity (Pauling Scale) 3.16
Chlorine Electrons per Orbital Shell (inner most first) 2, 8, 7
Chlorine Half-Life (Years) N/A - Stable
Chlorine Lattice Parameter / Lattice Constant (Å) a = 6.24, b = 3.94, c = 4.95
Chlorine Number of Electron Orbital Shells 3
Chlorine Number of Electrons 17
Chlorine Number of Neutrons 17
Chlorine Number of Protons 17
Chlorine Periodic Table Series Halogens
Chlorine Phase at 'Standard Temperature and Pressure' Gas
Chlorine Stable Isotopes Cl-35, Cl-37

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Electrical Properties of Chlorine

Electrical Property (Units) Value
Chlorine Dielectric Constant at 'Standard Temperature and Pressure' 1.00115
Chlorine Electrical Breakdown Voltage at Atmospheric Pressure (kV/mm) Unknown
Chlorine Electrical Conductivity (S/m) Unknown
Chlorine Electrical Resistivity at Room Temperature (25°C) (Ω·m) Unknown
Chlorine Magnetic Property Diamagnetic
Chlorine Superconducting Transition Temperature (K) N/A - Not a Super Conductor
Chlorine Temperature Coefficient of Resistance (°C⁻¹) N/A

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Mechanical Properties of Chlorine

Mechanical Property (Units) Value
Chlorine Compressive Strength (MPa) Unknown
Chlorine Ductile to Brittle Transition Temperature (°C) Unknown
Chlorine Fatigue Limit (MPa) Unknown
Chlorine Fracture Toughness (MPa·√m) Unknown
Chlorine Hardness Brinell Unknown
Chlorine Hardness Rockwell Unknown
Chlorine Hardness Vickers Unknown
Chlorine Heat Deflection Temperature (°C) N/A - Not a Polymer
Chlorine Modulus of Elasticity / Young's Modulus (GPa) Unknown
Chlorine Percent Elongation (%) Unknown
Chlorine Poissons Ratio Unknown
Chlorine Shear Modulus (GPa) Unknown
Chlorine Shear Strength (MPa) Unknown
Chlorine Ultimate Tensile Strength (MPa) Unknown
Chlorine Yield Strength (MPa) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Physical Properties of Chlorine

Physical Property (Units) Value
Chlorine Boiling Point at Atmospheric Pressure (°C) -34.04
Chlorine Chemical Composition (Element %) Cl
Chlorine Cost ($/kg) 0.3
Chlorine Density at 'Standard Temperature and Pressure' (kg/m3) 3.214
Chlorine Glass Transition Temperature at Atmospheric Pressure (°C) N/A
Chlorine Melting Point at Atmospheric Pressure (°C) −101.5
Chlorine Polymer Family N/A - Not a Polymer
Chlorine Refractive Index 1.001
Chlorine Specific Gravity 0.003214
Chlorine Viscosity at Melting Point (mPa·s) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and POLYMERS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Thermal Properties of Chlorine

Thermal Property (Units) Value
Chlorine Coefficient of Thermal Expansion (µm/m·K) Unknown
Chlorine Emissivity Coefficient Unknown
Chlorine Specific Heat Capacity (J/kg·K) 479
Chlorine Thermal Conductivity (W/m.K) 0.0089
Chlorine Thermal Conductivity (BTU/h·ft·°F) 0.01
