Properties and Overview of Platinum
Overview:
Platinum (Pt) is a dense, malleable, and precious metal with the symbol Pt and atomic number 78. It belongs to the group of transition metals in the periodic table. It is renowned for its remarkable physical and chemical properties, including high corrosion resistance, excellent catalytic capabilities, and a silvery-white appearance. Historically, platinum has been recognized for its rarity and has often been associated with wealth and prestige, but it also plays a crucial role in various industrial and technological applications due to its unique characteristics.
Physically, platinum is a heavy metal with a density of 21.45g/cm3, making it one of the densest elements known. It has a melting point of 1,768°C and a boiling point of 3,825°C, indicating its ability to withstand extremely high temperatures without degrading. Platinum's malleability and ductility are comparable to gold, allowing it to be easily shaped and drawn into wires or thin sheets. It has a face-centered cubic (FCC) crystal structure, contributing to its mechanical properties and high resistance to deformation. Platinum's appearance is typically bright and lustrous, with a silver-white color that does not tarnish, making it highly desirable for jewelry and decorative items.
Chemically, platinum is one of the least reactive metals, exhibiting exceptional oxidation resistance, even at high temperatures. It does not corrode in air and is unaffected by most acids, which enhances its durability in various environments. Platinum is resistant to hydrochloric acid, but it can be dissolved in aqua regia, a mixture of nitric acid and hydrochloric acid, one of the few substances capable of dissolving it. The metal's inertness makes it an excellent choice for applications requiring stability and chemical reaction resistance. Platinum readily forms complexes and can exist in several oxidation states, most commonly +2 and +4. These properties make platinum an essential catalyst in various chemical reactions, including hydrogenation, oxidation, and reforming processes. Platinum compounds, such as cisplatin, are also significant in medical applications, particularly in cancer treatment, due to their ability to interfere with DNA replication in cancer cells.
Safety considerations when handling platinum generally focus on its compounds rather than the metal itself, as metallic platinum is considered non-toxic and hypoallergenic, making it safe for use in medical implants and jewelry. However, some platinum compounds, especially those used in chemotherapy, are highly toxic and can cause side effects such as kidney damage, hearing loss, and nausea. Additionally, the dust and fumes generated during the processing of platinum can be harmful if inhaled, potentially causing respiratory issues. Thus, adequate protective measures, including proper ventilation and personal protective equipment, are essential in environments where platinum compounds are handled. Despite its relative safety, careful handling is necessary when working with platinum compounds due to their potent biological activity and potential environmental impact.
Applications:
Platinum's applications are diverse and extend across multiple industries due to its unique properties. In the automotive industry, platinum is a critical component in catalytic converters, where it serves as a catalyst to reduce harmful emissions by converting carbon monoxide, hydrocarbons, and nitrogen oxides into less harmful substances like carbon dioxide, water vapor, and nitrogen. This application alone accounts for a significant portion of platinum demand globally. In the chemical industry, platinum catalysts are used in the production of silicones, nitric acid, and various petrochemicals. Platinum is also used in the refining of petroleum, which helps crack hydrocarbons to produce gasoline and other fuels.
Summary:
Platinum is likely to remain a crucial material in emerging technologies, such as renewable energy systems and advanced electronics. The development of fuel cell technologies, which utilize platinum as a catalyst, is expected to increase demand for the metal in the coming decades. Overall, platinum's rarity, versatility, and durability ensure its continued importance across industries, making it one of the most valuable and sought-after metals in the world.
See a comprehensive list of atomic, electrical, mechanical, physical and thermal properties for platinum below:
Atomic Structure of Platinum
Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY
Require different units not displayed?
CONVERT VARIOUS UNITS HERE
Atomic Properties of Platinum
Atomic Property (Units) | Value |
---|---|
Platinum Atomic Electron Configuration | [Xe] 4f145d96s1 |
Platinum Atomic Mass (amu) | 195.08 |
Platinum Atomic Number | 78 |
Platinum Chemical Element Symbol | Pt |
Platinum Covalent Radius (Å) | 1.36 |
Platinum Crystal Structure | Face-Centered Cubic (FCC) |
Platinum Electronegativity (Pauling Scale) | 2.28 |
Platinum Electrons per Orbital Shell (inner most first) | 2, 8, 18, 32, 17, 1 |
Platinum Half-Life (Years) | N/A - Stable |
Platinum Lattice Parameter / Lattice Constant (Å) | a = 3.92 |
Platinum Number of Electron Orbital Shells | 6 |
Platinum Number of Electrons | 78 |
Platinum Number of Neutrons | 78 |
Platinum Number of Protons | 78 |
Platinum Periodic Table Series | Transition Metals |
Platinum Phase at 'Standard Temperature and Pressure' | Solid |
Platinum Stable Isotopes | Pt-195 |
Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY
Require different units not displayed?
CONVERT VARIOUS UNITS HERE
Electrical Properties of Platinum
Electrical Property (Units) | Value |
---|---|
Platinum Dielectric Constant at 'Standard Temperature and Pressure' | Unknown |
Platinum Electrical Breakdown Voltage at Atmospheric Pressure (kV/mm) | Unknown |
Platinum Electrical Conductivity (S/m) | 9.4E+06 |
Platinum Electrical Resistivity at Room Temperature (25°C) (Ω·m) | 1.064E-07 |
Platinum Magnetic Property | Paramagnetic |
Platinum Superconducting Transition Temperature (K) | N/A - Not a Super Conductor |
Platinum Temperature Coefficient of Resistance (°C⁻¹) | +0.00392 (3920 ppm/°C) |
Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY
Require different units not displayed?
CONVERT VARIOUS UNITS HERE
Mechanical Properties of Platinum
Mechanical Property (Units) | Value |
---|---|
Platinum Compressive Strength (MPa) | 500 - 550 |
Platinum Ductile to Brittle Transition Temperature (°C) | None (Ductile Always) |
Platinum Fatigue Limit (MPa) | 900 |
Platinum Fracture Toughness (MPa·√m) | 20 |
Platinum Hardness Brinell | 40 - 50 |
Platinum Hardness Rockwell | 20 - 40 (HRB) |
Platinum Hardness Vickers | 40 - 50 |
Platinum Heat Deflection Temperature (°C) | N/A - Not a Polymer |
Platinum Modulus of Elasticity / Young's Modulus (GPa) | 168 - 170 |
Platinum Percent Elongation (%) | 25 - 30 |
Platinum Poissons Ratio | 0.39 |
Platinum Shear Modulus (GPa) | 61 |
Platinum Shear Strength (MPa) | 80 - 100 |
Platinum Ultimate Tensile Strength (MPa) | 125 |
Platinum Yield Strength (MPa) | 70 |
Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY
Require different units not displayed?
CONVERT VARIOUS UNITS HERE
Physical Properties of Platinum
Physical Property (Units) | Value |
---|---|
Platinum Boiling Point at Atmospheric Pressure (°C) | 3825 |
Platinum Chemical Composition (Element %) | Pt |
Platinum Cost ($/kg) | 40000 |
Platinum Density at 'Standard Temperature and Pressure' (kg/m3) | 21450 |
Platinum Glass Transition Temperature at Atmospheric Pressure (°C) | N/A |
Platinum Melting Point at Atmospheric Pressure (°C) | 1768 |
Platinum Polymer Family | N/A - Not a Polymer |
Platinum Refractive Index | Unknown |
Platinum Specific Gravity | 21.45 |
Platinum Viscosity at Melting Point (mPa·s) | 5.8 |
Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY
Require different units not displayed?
CONVERT VARIOUS UNITS HERE
Thermal Properties of Platinum
Thermal Property (Units) | Value |
---|---|
Platinum Coefficient of Thermal Expansion (µm/m·K) | 8.8 |
Platinum Emissivity Coefficient | 0.02 - 0.04 |
Platinum Specific Heat Capacity (J/kg·K) | 133 |
Platinum Thermal Conductivity (W/m.K) | 71.6 |
Platinum Thermal Conductivity (BTU/h·ft·°F) | 41.40 |
