Polymer Structure

Properties and Overview of PVA (Polyvinyl Alcohol)

Overview:

Image of PVA or Application PVA (Polyvinyl Alcohol) is a water-soluble polymer known for its exceptional film-forming, adhesive, and emulsifying properties. It is widely used in industries that require materials with strong chemical resistance, flexibility, and biodegradability. Its non-toxic and environmentally friendly characteristics make PVA an essential polymer in applications ranging from packaging and textiles to adhesives and medical products.


Production:

The production of PVA involves the hydrolysis or alcoholysis of polyvinyl acetate (PVAc). During this process, the acetate groups in PVAc are replaced with hydroxyl groups, resulting in a polymer that dissolves in water. The degree of hydrolysis determines the solubility and properties of the final PVA material, allowing manufacturers to tailor it for specific applications. PVA can be processed into films, fibers, or solutions and is often blended with other materials to enhance performance.


Applications:

PVA's applications are extensive due to its unique combination of properties. In the packaging industry, it produces water-soluble films for single-use pouches, such as those for detergents and agrochemicals, offering a convenient and environmentally friendly solution. In textiles, PVA is employed as a warp sizing agent to strengthen yarns during weaving, ensuring smoother operations and higher-quality fabrics. The polymer is also a key ingredient in adhesives, where its strong bonding capabilities are used in woodworking, paper products, and laminations. In the medical field, PVA is used for wound dressings, eye drops, and drug delivery systems, benefiting from its biocompatibility and ability to form hydrogels. Additionally, PVA is applied in construction for cement additives and coatings, improving flexibility and durability.


Summary:

Polyvinyl Alcohol is a versatile and environmentally friendly polymer that combines water solubility, strength, and chemical resistance. Its adaptability to diverse applications, from sustainable packaging to advanced medical products, ensures its continued importance in modern industries. As demand for sustainable and biodegradable materials grows, PVA's unique properties and eco-friendly profile are vital in addressing global environmental challenges. Its widespread applications highlight its significance as a key material driving innovation and sustainability across various sectors.



See a comprehensive list of electrical, mechanical, physical and thermal properties for PVA (Polyvinyl Alcohol) below:



Electrical Properties of PVA (Polyvinyl Alcohol)

Electrical Property (Units) Value
PVA (Polyvinyl Alcohol) Dielectric Constant at 'Standard Temperature and Pressure' 2.0 to 2.5
PVA (Polyvinyl Alcohol) Electrical Breakdown Voltage at Atmospheric Pressure (kV/mm) ~25 to 30
PVA (Polyvinyl Alcohol) Electrical Conductivity (S/m) 1.00E-14 to 1.00E-12
PVA (Polyvinyl Alcohol) Electrical Resistivity at Room Temperature (25°C) (Ω·m) 1.00E+12 to 1.00E+14
PVA (Polyvinyl Alcohol) Magnetic Property N/A
PVA (Polyvinyl Alcohol) Superconducting Transition Temperature (K) N/A
PVA (Polyvinyl Alcohol) Temperature Coefficient of Resistance (°C⁻¹) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and CHEMICAL ELEMENTS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Mechanical Properties of PVA (Polyvinyl Alcohol)

Mechanical Property (Units) Value
PVA (Polyvinyl Alcohol) Compressive Strength (MPa) 20 to 60
PVA (Polyvinyl Alcohol) Ductile to Brittle Transition Temperature (°C) ~0
PVA (Polyvinyl Alcohol) Fatigue Limit (MPa) Unknown
PVA (Polyvinyl Alcohol) Fracture Toughness (MPa·√m) 1.0 to 2.0
PVA (Polyvinyl Alcohol) Hardness Brinell ~10
PVA (Polyvinyl Alcohol) Hardness Rockwell 40 to 60 HRR
PVA (Polyvinyl Alcohol) Hardness Vickers ~10
PVA (Polyvinyl Alcohol) Heat Deflection Temperature (°C) 70 to 90
PVA (Polyvinyl Alcohol) Modulus of Elasticity / Young's Modulus (GPa) 2.0 to 4.0
PVA (Polyvinyl Alcohol) Percent Elongation (%) 5 to 10
PVA (Polyvinyl Alcohol) Poissons Ratio 0.33
PVA (Polyvinyl Alcohol) Shear Modulus (GPa) ~1.0
PVA (Polyvinyl Alcohol) Shear Strength (MPa) 20 to 30
PVA (Polyvinyl Alcohol) Ultimate Tensile Strength (MPa) 40 to 60
PVA (Polyvinyl Alcohol) Yield Strength (MPa) 30 to 50

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and CHEMICAL ELEMENTS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Physical Properties of PVA (Polyvinyl Alcohol)

Physical Property (Units) Value
PVA (Polyvinyl Alcohol) Boiling Point at Atmospheric Pressure (°C) Decomposes
PVA (Polyvinyl Alcohol) Chemical Composition (Element %) (C2H4O)n
PVA (Polyvinyl Alcohol) Cost ($/kg) 3 to 6
PVA (Polyvinyl Alcohol) Density at 'Standard Temperature and Pressure' (kg/m3) 1190 to 1310
PVA (Polyvinyl Alcohol) Glass Transition Temperature at Atmospheric Pressure (°C) 80 to 85
PVA (Polyvinyl Alcohol) Melting Point at Atmospheric Pressure (°C) ~200 to 230
PVA (Polyvinyl Alcohol) Polymer Family Thermoplastic
PVA (Polyvinyl Alcohol) Refractive Index 1.50 to 1.53
PVA (Polyvinyl Alcohol) Specific Gravity 1.19 to 1.31
PVA (Polyvinyl Alcohol) Viscosity at Melting Point (mPa·s) Unknown

Unfamiliar with a property? Click it's description to be given a full definition in the GLOSSARY

See properties and overview for
ALLOYS and CHEMICAL ELEMENTS
popular in engineering

Require different units not displayed?
CONVERT VARIOUS UNITS HERE

Thermal Properties of PVA (Polyvinyl Alcohol)

Thermal Property (Units) Value
PVA (Polyvinyl Alcohol) Coefficient of Thermal Expansion (µm/m·K) 50 to 100
PVA (Polyvinyl Alcohol) Emissivity Coefficient ~0.9
PVA (Polyvinyl Alcohol) Specific Heat Capacity (J/kg·K) ~1720
PVA (Polyvinyl Alcohol) Thermal Conductivity (W/m.K) 0.2
PVA (Polyvinyl Alcohol) Thermal Conductivity (BTU/h·ft·°F) 0.12
